| Model Number : | RJ45S/C40/O |
| Price : | Negotiable |
| Brand Name : | KRONZ |
| Certification : | CE |
| Payment Terms : | T/T,Western Union,MoneyGram |
| Supply Ability : | 100000 pieces per month |
| Delivery Time : | 5-8 working days |
The Fast Connect RJ45 Connector (145 Series, 4-Pin, 100Mbit/s) is a ruggedized, industrial-grade Ethernet plug designed for high-performance data transmission in demanding environments. It combines tool-less termination, robust metal housing, and optimized pin configuration for Fast Ethernet (10/100Mbit/s) applications where durability and quick installation are critical.

| Pin assignment | 4 PIN |
| Contact nut material | Zinc alloy, nickle-plated |
| Contact surface material | Brass, gold-plated |
| Contact carrier material | Zinc alloy, nickle-plated |
| Contact method | IDC |
| Degree of protection | IP20 |
| Transmission characteristics | ≥Cat5 |
| Data rate | ≥ 10/100 Mbit/s |
| Power transmission | POE,POE+ |
| Ambient temperature | -20~+70℃ |
| Mating cycles | ≥10 |
| Pin assignment | Type | Rated current | Voltage | Wire gauge | Cable outlet | Model No. |
![]() | RJ45 | 1.5A | 45V | 0.14~0.34 mm² 26~22 AWG cable diameter: 6.5mm | Straight | RJ45S/C40/O |





|
