240W AC/DC Industrial Power Supplies Active PFC Rail Mounted

240W Power AC/DC Input Indoor Use 12V/16A Industrial Power Supply Active PFC

Industrial power supply 192W, 12V/16A provide customers with cost-effective, standard rail-mounted, efficient and energy-saving green power supplies.

Providing high stability and high anti-interference power supply for industrial control equipment, machines and other industrial
equipment in various harsh environments. The power supply is small in size, light in weight, compact in structure, and standard railmounted,
saving customers a lot of space, the product is safe and reliable.

Features:

Input voltage:Universal 85 - 264VAC/120 - 370VDC
Accepts AC or DC Input(dual-use of same termlnal)
Operating amblent temperature range:-40℃ to +70℃
High efficiency, high reliability
DC OK function
Active PFC
150% peak power for 3 seconds of continuous output
Power supply start LED indicator light
Output short circult, over-current,over-voltage, over-temperature protection
Satisfy 5000m altitude applications
Overvoltage level II
Indoor use

Selection Guide

Model No.

Output Power

Nominal Output Voltage&Current (Vo/lo)

Output Voltage Adjustable Range (V)

Efficiency at 230VAC (%) Typ.

Max. Capacitive Load (μF)

PRF240-12A30

192

12V/16A

12.0-14.0

160,000

Input Specifications
Item	Operating Conditions		Min.	Typ.	Max.	Unit
Input Voltage Range	Rated input (certified voltage)		100	--	240	VAC
	AC input		85	--	264
	DC input		120	--	370	VDC
Input Voltage Frequency	Rated AC input		50	--	60	Hz
	AC input		47	--	63
Input Current	Rated input		--	--	3	A
	115VAC		--	--	3
	230VAC		--	--	1.5
Inrush Current	115VAC	Cold start	--	15	--
	230VAC		--	30	--
Leakage Current	264VAC		<0.5mA
Power Factor	115VAC		--	0.98	--	--
	230VAC		--	0.94	--
Hot Plug			Unavailable

Output Specifications
Item	Operating Conditions		Min.	Typ.	Max.	Unit
Output Voltage Accuracy	Full load range	12V	--	±2.0	--	%
Line Regulation	Rated load		--	±1.0	--
Load Regulation	0% - 100% load		--	±0..5	--
Ripple & Nolse	20MHz bandwidth (peak-peak value)	12V	--	50	100	mv
Standby Power			--	4	--	W
Power-off retention time			--	20	--	ms
DC OK Function	Resistive load		30VDC/1A Max.
Short Circuit Protection	Recovery time < 10s after the short circuit disappear		Hiccup mode,constant current works 1s,turn off 10s,continuous,self-recovery
Over-current Protection	230VAC,rated load	Normal temperature, high temperature	105%-200%lo,self recovery
Over-current Protection	230VAC,rated load	Low temperature	≥105%lo, self-recovery
Over-voltage Protection	12V		≤18V	Hiccup, can self recover after the abnormal state is resolved
Over-temperature Protection	230VAC Rated Ioad		--	80	--	℃
Note:The"tip and barrel method"is used for ripple and noise test,output parallel 47uF electrolytic capacitor and 0.1uF ceramic capacitor,please refer to Enclosed Switching Power Supply Application Notes for specific information; 2.*DC OK Signal: When the output voltage is normal, the relay is connected. When the output voltage is abnormal(<90%Vo),the relay is disconnected.

General Specifications
Item		Operating Conditions			Min.	Typ.	Max.	Unit
Isolation Test	Input-	Electric strength test for 1min,leakage current＜15mA			2000	--	--	VAC
	Input-Output				3000	--	--
	Output-				500	--	--
Insulation Resistance	Input-	Test voltage: 500VDC			50	--	--	MΩ
	Input-Output				50	--	--
	Output-				50	--	--
Operating Temperature					-40	--	+70	℃
Storage Temperature					-40	--	+85
Storage Humidity		Non-condensing			--	--	95	%RH
Operating Humidity					--	--	90
Switching Frequency					--	100	--	kHz
Output Power Derating		Operating temperature derating	-40℃ to -25 ℃		3.34	--	--	%℃
			+45℃ to +70 ℃	115VAC	2.0	--	--
			+50℃ to +70 ℃	12V, 230VAC	1.25	--	--
			+60℃ to +70 ℃	Other, 230VAC	3.0	--	--
		Input voltage derating	85VAC-100VAC		0.67	--	--	%VAC
Safety Standards		12V			UL61010-1,UL61010-2-201 safety approved&EN62368-1 Comform to IEC/UL/BS EN 62368-1
Safety Class					CLASS I
MTBF		MIL-HDBK-217F@25℃			＞300,000 h
Pollution degree					2

Physical Characteristics
Case Material	Metal (AL5052,SPCC)
Dimensions	124.00 x 41.00 x 110.00 mm
Weight	650g (Typ.)
Cooling Method	Free air convection

EMC Characteristics
EMI	CE	CISPR32/EN55032 CLASS B
	RE	CISPR32/EN55032 CLASS B
	Harmonic current	IEC/EN 61000-3-2 CLASS A and CLASS D
EMS	ESD	IEC/EN 61000-4-2 Contact ±6KV/Air ±8KV	perf. Criteria A
	PS	IEC/EN 61000-4-3 10V/m	perf. Criteria A
	EFT	IEC/EN 61000-4-4 ±4KV	perf. Criteria A
	Surge	IEC/EN 61000-4-5 line to line ±2KV/line to ground ±4KV	perf. Criteria A
	CS	IEC/EN61000-4-6 10 Vr.m.s	perf. Criteria A
	Voltage dips,short interruptions and voltage variations immunity	IEC/EN61000-4-11 0%, 70%	perf. Criteria A
